PODNOŽJE: INTEL LGA 1700
ZA PROCESORJE:
Support for the 14th, 13th, and 12th Generation Intel®
Core™, Pentium®
Gold and Celeron®
Processors
FORMAT:
mini ITX Form Factor 17cm x 17cm
VEZNI ČIP:
Intel H610
POMNILNIK:
2 x DDR5 DIMM (do
5600/5200/4800/4400MHz) do skupno 64GB kapacitete,
Dual channel memory architecture,
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode),
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules,
Support for Extreme Memory Profile (XMP) memory modules
GRAFIKA:
DA - preko CPU
RAID:
NE
RAZšIRITVENE REŽE:
1 x PCI Express 4.0 x16
MREŽNA KARTICA: Intel LAN chip (10/100/1000 Mbit)
ZVOČNA KARTICA:
Realtek audio codec High Definition Audio (2/4/5.1/7.1-channel)
NOTRANJI PRIKLJUČKI:
1 x 24-pin ATX main power connector
1 x 4-pin ATX 12V power connector
1 x CPU fan header
1 x system fan header
1 x RGB LED strip header
1 x M.2 Socket 3 connector
4 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x speaker header
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x Clear CMOS jumper
1 x chassis intrusion header
ZUNANJI PRIKLJUČKI:
1 x PS/2 keyboard/mouse port
2 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x D-Sub port
2 x DisplayPorts
1 x HDMI port
1 x RJ-45 port
3 x audio jacks
DODATNO:iTE® I/O Controller Chip
H/W Monitoring
Voltage detection
Temperature detection
Fan speed detection
Fan fail warning
Fan speed control
BIOS
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Unique Features
Support for APP Center
- @BIOS
- EasyTune
- Ambient LED
- Smart Backup
- System Information Viewer
Support for Q-Flash
Support for Xpress Install
Bundled Software
Norton® Internet Security (OEM version)
LAN bandwidth management softwareSpletna stran proizvajalca:
https://www.gigabyte.com/Motherboard/H610I-rev-10#kf
MB-340445
